Shin-Etsu Silicone Rubber for Molding Selection Guide

KE-2300-36-A/B

Main features Pressure fixinginsulation
  • For general use. Applications such as pressure fixing rolls
  • Low compression set, wear resistance.
  • Applications such as printer rolls

Product Information

Appearance Reddish brown
Viscosity A/B (Pa・s) 53/49
Curing speed at 130℃ (MDR)Ｔ10 22
Curing speed at 130℃ (MDR)Ｔ90 65
Curing conditions (Primary cure) 120℃×10m
Curing conditions (Post cure) 200℃×4h
Hardness Durometer A 36*
Density at 23℃ (g/cm3) 1.24
Tensile strength (MPa) 1.0
Elongation at break (%) 180
Compression set (%) 2**

(Not specified values)

* Asker C
** Curing condition: 120℃ × 15 min + 200℃ × 4 h, testing condition: 180℃ × 22 h

Product Inquiry

KE-2300-36-A/B

Inquiry Form

Contact by Telephone or Fax

Related Material

Silicone Rubber for Molding（3.0MB）

Characteristic properties of Silicone Rubber Compounds（1.0MB）

Related Product List

Product name Grade and features Appearance Viscosity A/B(Pa・s) Curing speed at
130℃(MDR)Ｔ10		 Curing speed at
130℃(MDR)Ｔ90		 Curing conditions
(Primary cure)		 Curing conditions
(Post cure)		 Hardness Durometer A Density at 23℃
(g/cm3)		 Linear shrinkage at 150℃ Tensile strength (MPa) Elongation at break (%) Tear strength Crescent piece
(kN/m)		 Compression set
150℃ × 22 h(%)
KE-1950-10-A/B General use, low viscosity Translucent 60/60 47 105 120℃ × 5 m 150℃ × 1 h 13 1.08 2.6 4.3 750 10 12*1
KE-1950-20-A/B General use, low viscosity Translucent 160/160 47 109 120℃ × 5 m 150℃ × 1 h 20 1.1 2.5 7.3 970 24 15*1
KE-1950-30-A/B General use, conforms to food standards, low viscosity Translucent 250/250 31 55 120℃ × 5 m 150℃ × 1 h 31 1.1 2.5 8.2 710 22 22*1
KE-1950-40-A/B General use, conforms to food standards, low viscosity Translucent 530/530 29 58 120℃ × 5 m 150℃ × 1 h 39 1.12 2.5 9.3 670 31 20*1
KE-1950-50-A/B General use, conforms to food standards, low viscosity Translucent 680/630 37 73 120℃ × 5 m 150℃ × 1 h 49 1.13 2.5 8.9 560 37 28*1
KE-1950-60-A/B General use, conforms to food standards, low viscosity Translucent 730/690 37 78 120℃ × 5 m 150℃ × 1 h 57 1.14 2.5 8.0 420 39 22*1
KE-1950-70-A/B General use, conforms to food standards, low viscosity Translucent 680/650 36 65 120℃ × 5 m 150℃ × 1 h 68 1.13 2.5 9.5 470 39 34*1
KEG-2000-20-A/B General use Translucent 700/700 27 48 120℃ × 5 m 150℃ × 1 h 23 1.08 2.6 6.2 880 15 28*2
KEG-2000-30-A/B General use, conforms to food standards Translucent 1200/1200 33 65 120℃ × 5 m 150℃ × 1 h 32 1.12 2.5 9.2 830 28 14*2
KEG-2000-40-A/B General use, conforms to food standards Translucent 1300/1300 33 57 120℃ × 5 m 150℃ × 1 h 43 1.12 2.5 9.2 630 34 17*2
KEG-2000-50-A/B General use, conforms to food standards Translucent 1400/1400 33 60 120℃ × 10 m 150℃ × 1 h 51 1.14 2.5 12.7 670 38 11*2
KEG-2000-60-A/B General use, conforms to food standards Translucent 1600/1600 43 79 120℃ × 10 m 150℃ × 1 h 60 1.14 2.5 11.5 550 48 20*2
KEG-2000-70-A/B General use, conforms to food standards Translucent 1400/1400 37 70 120℃ × 10 m 150℃ × 1 h 70 1.14 2.5 10.8 470 34 18*2
KEG-2000-80-A/B General use, conforms to food standards Translucent 1120/1080 35 65 120℃ × 10 m 150℃ × 1 h 81 1.13 2.5 8.0 200 5 －
KEG-2001-40-A/B General use, conforms to food standards, Fast curing Translucent 1000/1000 26 45 120℃ × 10 m 150℃ × 1 h 42 1.12 2.5 11.0 630 33 15*2
KEG-2001-50-A/B General use, conforms to food standards, Fast curing Translucent 1000/1000 26 45 120℃ × 10 m 150℃ × 1 h 52 1.13 2.5 11.8 530 40 12*2
KEG-2001-60-A/B General use, conforms to food standards, Fast curing Translucent 1320/1280 24 51 120℃ × 5 m 150℃ × 1 h 60 1.13 2.5 9.2 550 44 19*2
KEG-2001-70-A/B General use, conforms to food standards, Fast curing Translucent 1200/1200 26 46 120℃ × 5 m 150℃ × 1 h 70 1.14 2.5 9.5 420 40 20*2
KEG-2003H-30-A/B No post cure (Reduced low-molecular-weight siloxone content), conforms to food standards, high tear strength Translucent 740/690 23 44 150℃ × 5 m － 31 1.13 2.5 9.3 900 30 21*3
KEG-2003H-40-A/B No post cure (Reduced low-molecular-weight siloxone content), conforms to food standards, high tear strength Translucent 900/960 23 45 150℃ × 5 m － 41 1.13 2.5 9.1 830 36 15*3
KEG-2003H-50-A/B No post cure (Reduced low-molecular-weight siloxone content), conforms to food standards, high tear strength Translucent 1030/1000 21 41 150℃ × 5 m － 51 1.13 2.5 10.6 790 40 15*3
KEG-2003H-60-A/B No post cure (Reduced low-molecular-weight siloxone content), conforms to food standards, high tear strength Translucent 750/700 22 43 150℃ × 5 m － 60 1.13 2.5 9.9 660 46 19*3
KEG-2003H-70-A/B No post cure (Reduced low-molecular-weight siloxone content), conforms to food standards, high tear strength Translucent 1040/1010 30 61 150℃ × 5 m － 69 1.14 2.4 9.1 490 46 28*3
KE-2017-20-A/B No post cure (Reduced low-molecular-weight siloxone content), oil breeding Translucent 610/490 31 86 150℃ × 10 m － 24 1.1 2.5 7.4 840 13*5 13*4
KE-2017-30-A/B No post cure (Reduced low-molecular-weight siloxone content), oil breeding Translucent 1940/1590 44 85 150℃ × 10 m － 32 1.14 2.4 8.9 740 22*5 18*4
KE-2017-40-A/B No post cure (Reduced low-molecular-weight siloxone content), oil breeding Translucent 1790/1550 35 76 150℃ × 10 m － 43 1.14 2.4 9.0 620 34*5 18*4
KE-2017-50-A/B No post cure (Reduced low-molecular-weight siloxone content), oil breeding Translucent 2030/1710 33 72 150℃ × 10 m － 50 1.14 2.4 9.3 480 40*5 18*4
KE-2019-30-A/B No post cure (Reduced low-molecular-weight siloxone content), low compression set Translucent 342/370 32 95 150℃ × 10 m － 32 1.12 2.5 8.7 738 20*5 15*4
KE-2019-40-A/B No post cure (Reduced low-molecular-weight siloxone content), low compression set Translucent 327/334 31 78 150℃ × 10 m － 40 1.12 2.5 9.5 670 31*5 14*4
KE-2019-50-A/B No post cure (Reduced low-molecular-weight siloxone content), low compression set Translucent 840/710 25 52 150℃ × 10 m － 53 1.15 2.4 9.8 565 42*5 16*4
KE-2019-60-A/B No post cure (Reduced low-molecular-weight siloxone content), low compression set Translucent 693/773 33 63 150℃ × 10 m － 59 1.14 2.4 9.3 507 43*5 41*4
KE-2097-30-A/B No post cure (Reduced low-molecular-weight siloxone content), conforms to food standards, self-adhesive Translucent 620/670 19 55 150℃ × 5 m － 30 1.13 2.5 9.8 820 13 15*6
KE-2097-40-A/B No post cure (Reduced low-molecular-weight siloxone content), conforms to food standards, self-adhesive Translucent 964/898 21 44 150℃ × 5 m － 37 1.14 2.5 8.9 720 25 －
KE-2097-50-A/B No post cure (Reduced low-molecular-weight siloxone content), conforms to food standards, self-adhesive Translucent 500/546 21 47 150℃ × 5 m － 47 1.13 2.5 9.7 700 34 －
KE-2097-60-A/B No post cure (Reduced low-molecular-weight siloxone content), conforms to food standards, self-adhesive Translucent 623/613 25 63 150℃ × 5 m － 60 1.14 2.5 9.7 380 45 －
KE-2098-40-A/B No post cure (Reduced low-molecular-weight siloxone content), self-adhesive Translucent 819/797 23 60 150℃ × 5 m － 40 1.15 2.5 9.2 700 35 －
KE-2098-50-A/B No post cure (Reduced low-molecular-weight siloxone content), self-adhesive Translucent 890/850 24 54 150℃ × 5 m － 47 1.15 2.5 8.5 610 36 －
KE-2098-60-A/B No post cure (Reduced low-molecular-weight siloxone content), self-adhesive Translucent 870/790 22 47 150℃ × 5 m － 61 1.14 2.5 8.9 430 42 －
X-34-4347-A/B Low density Reddish brown 249/258 32 63 120℃ × 10 m 150℃ × 1 h 42 0.95 － 5.6 570 9 －
X-34-4352-A/B Low density Reddish brown 231/286 34 65 120℃ × 10 m 150℃ × 1 h 41 0.84 － 4.3 710 7 －
KE-2061-30-A/B High transparency Tranparent 36/23 26 82 120℃ × 10 m 150℃ × 1 h 30 1.02 2.8 3.5 350 3 －
KE-2061-40-A/B High transparency Tranparent 36/19 24 70 120℃ × 10 m 150℃ × 1 h 39 1.03 2.7 5.2 300 6 －
KE-2061-50-A/B High transparency Tranparent 36/16 23 58 120℃ × 10 m 150℃ × 1 h 50 1.03 2.7 6.3 230 6 －
KE-2061-60-A/B High transparency Tranparent 36/16 29 80 120℃ × 10 m 150℃ × 1 h 59 1.04 2.7 7.3 90 9 －
KE-2061-70-A/B High transparency Tranparent 27/8.4 29 79 120℃ × 10 m 150℃ × 1 h 70 1.06 2.6 11.0 84 6 －
KE-2061-80-A/B High transparency Tranparent 51/13 32 80 120℃ × 10 m 150℃ × 1 h 79 1.07 2.6 11.4 71 7 －
KE-2061-90-A/B High transparency Tranparent 68/70 29 79 120℃ × 10 m 150℃ × 1 h 86 1.08 2.6 6.0 40 6 －
X-34-4402-3-A/B High transparency Tranparent 34/14 22 76 120℃ × 10 m 150℃ × 1 h 72 1.07 2.6 8.5 88 9 －
X-34-4419-A/B High transparency Tranparent 74/14 23 78 120℃ × 10 m 150℃ × 1 h 78 1.08 2.6 10.0 82 8 －
X-34-4045-A/B Antistatic Translucent 860/890 37 78 120℃ × 5 m 150℃ × 1 h 49 1.14 2.5 8.9 560 33 －
X-34-4054-A/B Antistatic Translucent 540/690 31 64 120℃ × 5 m 150℃ × 1 h 73 1.14 2.5 7.5 230 7 －
KE-2300-12-A/B Pressure fixing, insulation Reddish brown 53/53 22 80 120℃ × 10 m 200℃ × 4 h 12*7 1.24 － 0.6 340 － 5*8
KE-2300-16-A/B Pressure fixing, insulation Reddish brown 51/48 24 78 120℃ × 10 m 200℃ × 4 h 16*7 1.24 － 0.6 290 － 4*8
KE-2300-20-A/B Pressure fixing, insulation Reddish brown 53/50 22 74 120℃ × 10 m 200℃ × 4 h 20*7 1.24 － 0.7 250 － 3*8
KE-2300-24-A/B Pressure fixing, insulation Reddish brown 52/46 22 67 120℃ × 10 m 200℃ × 4 h 24*7 1.24 － 0.8 220 － 2*8
KE-2300-28-A/B Pressure fixing, insulation Reddish brown 55/50 21 66 120℃ × 10 m 200℃ × 4 h 28*7 1.24 － 0.8 200 － 2*8
KE-2300-32-A/B Pressure fixing, insulation Reddish brown 51/44 20 61 120℃ × 10 m 200℃ × 4 h 32*7 1.24 － 0.9 190 － 2*8
KE-2300-36-A/B Pressure fixing, insulation Reddish brown 53/49 22 65 120℃ × 10 m 200℃ × 4 h 36*7 1.24 － 1.0 180 － 2*8
KE-2300-40-A/B Pressure fixing, insulation Reddish brown 51/47 22 63 120℃ × 10 m 200℃ × 4 h 40*7 1.24 － 1.0 160 － 2*8
KE-2300-44-A/B Pressure fixing, insulation Reddish brown 56/50 23 73 120℃ × 10 m 200℃ × 4 h 44*7 1.24 － 1.2 150 － 3*8
KE-2300-48-A/B Pressure fixing, insulation Reddish brown 51/50 22 71 120℃ × 10 m 200℃ × 4 h 48*7 1.24 － 1.4 140 － 3*8
KE-2310C-08-A/B Pressure fixing, electrical conductivity Black 92/89 25 80 120℃10 m 200℃4 h 8*7 1.02 － 0.4 500 － 7*8
KE-2310C-12-A/B Pressure fixing, electrical conductivity Black 87/86 24 77 120℃10 m 200℃4 h 12*7 1.02 － 0.5 480 － 7*8
KE-2310C-16-A/B Pressure fixing, electrical conductivity Black 88/87 24 77 120℃10 m 200℃4 h 16*7 1.02 － 0.5 450 － 6*8
KE-2310C-20-A/B Pressure fixing, electrical conductivity Black 87/86 22 72 120℃10 m 200℃4 h 20*7 1.02 － 0.5 400 － 5*8
KE-2310C-24-A/B Pressure fixing, electrical conductivity Black 87/84 21 65 120℃10 m 200℃4 h 24*7 1.02 － 0.6 350 － 4*8
KE-2310C-28-A/B Pressure fixing, electrical conductivity Black 88/83 21 66 120℃10 m 200℃4 h 28*7 1.02 － 0.6 300 － 4*8
KE-2310C-32-A/B Pressure fixing, electrical conductivity Black 89/84 20 59 120℃10 m 200℃4 h 32*7 1.02 － 0.7 290 － 4*8
KE-2310C-36-A/B Pressure fixing, electrical conductivity Black 91/85 19 58 120℃10 m 200℃4 h 36*7 1.02 － 0.7 270 － 3*8
KE-2310C-40-A/B Pressure fixing, electrical conductivity Black 87/80 20 60 120℃10 m 200℃4 h 40*7 1.02 － 0.7 230 － 3*8
X-34-2920-A/B Developing, electrical conductivity Black 32/27 22 61 120℃10 m 200℃4 h 20 1.03 - 0.9 200 - 3*8
X-34-2931-A/B Developing, electrical conductivity Black 31/34 34 65 120℃10 m 200℃4 h 33 1.04 － 1.6 190 － 3*8
X-34-2940-A/B Developing, electrical conductivity Black 64/69 35 70 120℃10 m 200℃4 h 42 1.06 - - 181 - 3*8
X-34-2950-A/B Developing, electrical conductivity Black 53/50 23 71 120℃10 m 200℃4 h 50 1.08 - 3.1 113 - 4*8
X-34-4137-A/B Electrical conductivity Black 1000/1450 22 63 120℃ × 10 m 200℃ × 4 h 44 1.14 2.4 6.8 570 32 －
X-34-4162-A/B Electrical conductivity Black 1190/1690 23 71 120℃ × 10 m 200℃ × 4 h 40 1.14 2.4 6.2 520 29 －
KE-1955-A/B Flame retardance Black 625/615 18 44 150℃ × 10 m － 54 1.25 － 9.0 510 23 7*10

*1Curing condition: 150℃ × 15 min + 150℃ × 1 h, Test condition: 150℃ × 22 h, *2Curing condition: 120℃ × 15 min + 200℃×4h, Test condition: 175℃ × 22 h, *3Curing condition: 150℃ × 15 min, Test condition: 120℃ × 22 h
*4Curing condition: 150℃ × 15 min, Test condition: 150℃ × 70 h, *5Angle piece *6Curing condition: 120℃ × 15 min, Test condition: 150℃ × 22 h, *7Asker C
*8Curing condition: 120℃ × 15 min + 200℃ × 4 h, Test condition: 180℃ × 22 h, *9Curing condition: 150℃ × 15 min + 200℃ × 4 h, Test condition: 180℃ × 22 h, *10Curing condition: 150℃ × 15 min, Test condition: 100℃ × 70 h
