Silicones greatly expand the potential of resins, enabling the creation of materials of higher quality and functionality.
Silicones are highly functional resins that combine the characteristics of both inorganic and organic substances and exhibit an array of useful properties including heat resistance, cold resistance, weatherability, dielectric properties, release properties and water repellency.
By introducing silicones into other resins, the user can create new resin materials with enhanced functionality that includes not only heat resistance, weatherability and flame resistance, but improved impact resistance, lubricity and flexibility.
With their enhanced functionality, these high-performance composite resins are lightweight and have excellent fabricating characteristics and are used in a myriad of fields including electric and electronics applications, automotive applications, electrical wire, and construction.
Silicones for resin modification are available in many forms such as silanes and silane coupling agents, resins, oligomers, silicone fluids, modified silicone fluids and powders, so the user can choose the right type of product for the intended application and usage conditions.
Application examples
- For resins: To improve lubricity, release properties, anti-blocking properties, impact resistance, stress-relieving properties and coloring properties.
- For rubbers: To improve surface smoothness, anti-wear properties, heat resistance, cold resistance and release properties.
- For resins: To improve light-diffusing properties, impact resistance, surface smoothness and anti-wear properties.
- For paints, inks, coating agents & waxes: To improve surface smoothness, pigment dispersibility and matting properties.
- As a raw material for cosmetics
- For resins: To improve heat resistance and adhesiveness.
- For paints: Paint modification.
- For polycarbonate: To improve flame retardancy.
- Highly weather-resistant coating agents
- Materials for modification of heat-resistant resins
- Coupling agents for organic/inorganic composite materials
- Surface modification agents, etc.
Product lineup
Silicone master pellets
| Base resin | Product name | Silicone content, % |
|---|---|---|
| PP (polypropylene) | X-22-2101 | 50 |
| LDPE (low density polyethylene) | X-22-2125H | 50 |
| EVA (ethylene vinyl acetate copolymer) | X-22-2138B | 40 |
| POM (polyacetal) | X-22-2102 | 40 |
| ABS | X-22-2184-30 | 30 |
(Not specified values)
Silicone emulsions
| Product name | Non-volatile content, % |
Particle size, nm | Ionicity |
|---|---|---|---|
| KM-9703 | 45 | 280 | Anionic |
| X-52-8026C | 32 | 180 | Anionic |
(Not specified values)
Dual-end reactive silicone fluids
| Reactive group | Product name | Viscosity, mm2/s | Reactive group equivalent weight, g/mol |
|---|---|---|---|
 |
KF-8010 | 12 | 430 |
| X-22-161A | 25 | 800 | |
| X-22-161B | 55 | 1,500 | |
| KF-8012 | 90 | 2,200 | |
 |
KF-105 | 15 | 490 |
| X-22-163A | 30 | 1,000 | |
| X-22-163B | 60 | 1,800 | |
| X-22-163C | 120 | 2,700 | |
 |
X-22-169AS | 30 | 500 |
| X-22-169B | 70 | 1,700 | |
 |
X-22-160AS | 35 | 470 |
| KF-6001 | 45 | 900 | |
| KF-6002 | 70 | 1,600 | |
| KF-6003 | 110 | 2,500 | |
 |
X-22-1821 | 100 | 1,600 |
 |
X-22-164A | 25 | 860 |
| X-22-164B | 55 | 1,600 | |
| X-22-164C | 90 | 2,400 | |
 |
X-22-162C | 220 | 2,300 |
 |
X-22-2290AS | 160 | 500 |
 |
X-22-167B | 60 | 1,700 |
| X-22-167C | 90 | 2,300 |
(Not specified values)
Single-end reactive silicone fluids
| Reactive group | Product name | Viscosity, mm2/s | Reactive group equivalent weight, g/mol |
|---|---|---|---|
|
X-22-173BX | 30 | 2,500 |
| X-22-173DX | 60 | 4,700 | |
|
X-22-170BX | 40 | 2,800 |
| X-22-170DX | 65 | 4,700 | |
 |
X-22-176DX | 130 | 3,200 |
| X-22-176GX-A | 400 | 14,000 | |
|
X-22-174DX | 60 | 4,600 |
| X-22-2426 | 200 | 12,000 | |
| X-22-2404 | 5 | 420 |
(Not specified values)
Reactive silicone fluids containing heterogeneous functional groups
| Reactive group |
Heterogeneous substitution group |
Product name | Viscosity, mm2/s |
Reactive group equivalent weight, g/mol |
|---|---|---|---|---|
| Hydroxy | Polyether | X-22-4272 | 270 | 1,100 |
| X-22-4952 | 100 | 1,200 | ||
| X-22-6266 | 400 | 1,200 | ||
| Amino | Polyether | X-22-3939A | 3,300 | 1,700 |
| Phenyl | X-22-1660B-3 | 550 | 2,200 | |
| Vinyl | X-22-9412 | 14 | 430 | |
| Epoxy | Polyether | KF-1002 | 5,000 | 4,500 |
| X-22-4741 | 380 | 2,500 | ||
| Phenyl | X-22-2000 | 170 | 610 | |
| Aralkyl | X-22-3000T | 2,000 | 250 |
(Not specified values)
| Type | Product name |
Shape | Avg. particle size, µm |
Particle size distribution, µm |
True specific gravity |
Water content, % |
|---|---|---|---|---|---|---|
| Rubber | KMP-597 | Spherical | 5 | 1 to 10 | 0.97 | 0.1 |
| KMP-598 | Spherical | 13 | 2 to 30 | 0.97 | 0.1 | |
| X-52-875 | Amorphous | 30 | 1 to 100 | 0.97 | 0.1 | |
| Resin | KMP-590 | Spherical | 2.0 | 1 to 4 | 1.3 | 1 |
| KMP-701 | Spherical | 3.5 | 1 to 6 | 1.3 | 1 | |
| X-52-854 | Spherical | 0.7 | 0.2 to 5 | 1.3 | 1 | |
| X-52-1621 | Spherical | 5.0 | 1 to 8 | 1.3 | 1 | |
| Hybrid | KMP-600 | Spherical | 5 | 1 to 15 | 0.99 | 0.1 |
| KMP-601 | Spherical | 12 | 2 to 25 | 0.98 | 0.1 | |
| KMP-602 | Spherical | 30 | 4 to 60 | 0.98 | 0.1 | |
| KMP-605 | Spherical | 2 | 0.7 to 5 | 0.99 | 0.1 | |
| X-52-7030 | Spherical | 0.8 | 0.2 to 2 | 1.01 | 0.1 | |
| KSP-100* | Spherical | 5 | 1 to 15 | 0.99 | 0.1 | |
| KSP-101* | Spherical | 12 | 2 to 25 | 0.98 | 0.1 | |
| KSP-102* | Spherical | 30 | 4 to 60 | 0.98 | 0.1 | |
| KSP-105* | Spherical | 2 | 0.7 to 5 | 0.99 | 0.1 | |
| KSP-300* | Spherical | 5 | 1 to 15 | 1.1 | 0.1 | |
| Silica | X-52-7042 | Spherical | 4 | 0.5 to 15 | 2.2 | 0.1 Max. |
| X-52-7043 | Spherical | 10 | 0.5 to 15 | 2.2 | 0.1 Max. | |
| X-24-9163A | Spherical | 0.1 | 0.1 | 1.8 | 2 |
* For personal care products. KSP-300 contains phenyl groups.
(Not specified values)Reactive organic group-containing silane coupling agents
| Functional group category |
Reactive group (Y) | Product name | Alkoxy groups | Reactive groups in applicable resin (W) |
|---|---|---|---|---|
| Amino | |
KBM-903 | Methoxy | Isocyanate groups, Epoxy groups |
| KBE-903 | Ethoxy | |||
 |
KBM-573 | Methoxy | ||
| Epoxy | |
KBM-403 | Methoxy | Amino groups, Hydroxyl groups, Carboxyl groups |
| KBE-402 | Ethoxy | |||
| KBE-403 | Ethoxy | |||
|
KBM-303 | Methoxy | ||
| Mercapto | |
KBM-802 | Methoxy | Isocyanate groups |
| KBM-803 | Methoxy | |||
| Isocyanate |  |
KBE-9007N | Ethoxy | Amino groups, Hydroxyl groups, Mercapto groups |
| Acid anhydride |  |
X-12-967C | Methoxy | Amino groups, Hydroxyl groups |
Polymerizable organic group-containing silane coupling agents
| Functional group category |
Reactive group (Y) | Product name | Alkoxy groups |
|---|---|---|---|
| Vinyl |  |
KBM-1003 | Methoxy |
| KBE-1003 | Ethoxy | ||
| Styryl |  |
KBM-1403 | Methoxy |
| Methacrylate | |
KBM-502 | Methoxy |
| KBM-503 | Methoxy | ||
| KBE-502 | Ethoxy | ||
| KBE-503 | Ethoxy | ||
| Acrylate |  |
KBM-5103 | Methoxy |
Nonreactive polar organic group-containing silane coupling agents
| Functional group category |
Reactive group (Y) | Product name | Alkoxy groups |
|---|---|---|---|
| Ureido |  |
KBE-585 | Ethoxy |
| Functional group category |
Product name | Alkoxy groups | Features |
|---|---|---|---|
| Methyl/Phenyl | KR-480 | - |
Solid resin, softening point: 95 °C |
Methyl silicone alkoxy oligomers
| Product name | Alkoxy groups |
Viscosity at 25 °C, mm2/s |
Refractive index, 25 °C |
Alkoxy group content, wt % |
Features |
|---|---|---|---|---|---|
| KC-89S | Methoxy | 5 | 1.394 | 45 | Low polymer, High hardness |
| KR-500 | Methoxy | 25 | 1.403 | 28 | Medium polymer |
| X-40-9225 | Methoxy | 100 | 1.407 | 24 | High polymer, Improves flexibility |
| X-40-9246 | Methoxy | 70 | 1.407 | 12 | Improves flexibility |
| X-40-9250 | Methoxy | 120 | 1.407 | 25 | Enables flexible, thick coatings |
(Not specified values)
Methyl phenyl silicone alkoxy oligomers
| Product name | Alkoxy groups |
Viscosity at 25 °C, mm2/s |
Refractive index, 25 °C |
Alkoxy group content, wt % |
Features |
|---|---|---|---|---|---|
| KR-9218 | Methoxy | 40 | 1.529 | 15 | Forms medium hardness coatings |
| KR-213 | Methoxy | 16 | 1.525 | 20 | High phenyl content |
| KR-510 | Methoxy | 100 | 1.509 | 17 | High hardness, low cost |
| X-40-9227 | Methoxy | 15 | 1.460 | 15 | Improves softness |
| X-40-9247 | Methoxy | 90 | 1.505 | 16 | High hardness, low volatile content |
(Not specified values)
Oligomers containing organic functional groups, and oligomers containing no organic groups
| Product name |
Organic substituent group |
Alkoxy groups |
Viscosity at 25 °C, mm2/s |
Refractive index, 25 °C |
Alkoxy group content, wt % |
Features |
|---|---|---|---|---|---|---|
| KR-517 | Epoxy | Methoxy /Ethoxy |
10 | 1.414 | 50 | Epoxy equivalent 830g/mol |
| X-41-1059A | Epoxy | Methoxy /Ethoxy |
30 | 1.434 | 43 | Epoxy equivalent 350 g/mol |
| KR-516 | Epoxy/Methyl | Methoxy | 50 | 1.442 | 17 | Epoxy equivalent 280 g/mol |
| X-41-1805 | Mercapto | Methoxy /Ethoxy |
20 | 1.417 | 50 | Mercapto equivalent 800 g/mol |
| X-41-1818 | Mercapto | Ethoxy | 15 | 1.416 | 60 | Mercapto equivalent 850 g/mol |
| X-41-1810 | Mercapto /Methyl |
Methoxy | 5 | 1.422 | 30 | Mercapto equivalent 450 g/mol |
| KR-513 | Acrylate /Methyl |
Methoxy | 35 | 1.450 | 20 | Acrylate equivalent 210 g/mol |
(Not specified values)
Room-temperature-cure coating agents
| Product name |
Organic substituent group |
Viscosity at 25 °C, mm2/s |
Refractive index, 25 °C |
Tack-free time, min |
Pencil hardness /Days cured |
Features |
|---|---|---|---|---|---|---|
| KR-400 | Methyl | 1.2 | 1.390 | 30 to 60 | 5H/2→8H/7 | High hardness |
| X-40-2327 | Methyl | 0.9 | 1.382 | 5 to 10 | 5H/1 | Rapid cure; Can be applied over other coatings |
| KR-401 | Methyl /Phenyl |
20 | 1.435 | 30 to 60 | 3H/7 | Flexural & impact resistance |
* Substrate: Polished steel sheet. Coating=10 µm, cured at 25 °C/70% RH.
(Tack-free time varies depending on temperature & humidity.)
